IEPE Power Supply for DIN Rail – IEPE USB Sensor Supply – IEPE Sensor Conditioner – IEPE Amplifier

IEPE compatible transducers. It has two channels input/output with BNC connector, and wide voltage power supply supports the use of various DC power supplies.

ICCP is a well-established standard which is widely used in the acoustic and vibration field to convert the high impedance signal of measurement microphones and piezoelectric transducers to a low impedance voltage output signal.

The abbreviation ICCP stands for “Integrated Constant Current Power” and has many manufacturer specific names such as ICP® (Integrated Circuit Piezoelectric), CCLD, DeltaTron®, ISOTRON® and IEPE (Integrate Electronics Piezoelectric)

PnDL-DIN

Analog Input	2ch single ended BNC, IEPE
Impedance	100 kOhm
IEPE power fixed	21 Volt / 4mA
Fixed input range	1, 5 or 10 Volt ^Peak
Bandwidth	1 Hz to 24 kHz (-3dB) 10 Hz to 22 kHz (-0.5dB)
Sampling Frequency	48 kHz, – 44.1 kHz – 32 kHz – 22.05 kHz 16 kHz – 11.025 kHz
Absolute accuracy	1 % typical
Gain accuracy	0.2 % or better
Distortion	< 0.05%
Dynamic range	> 100 dB（FFT-based)
Pass band ripple	0.05 dB
Powered by USB Port	Power consumption < 1W
Temperature range	+/-0 to +50 °C
Dimensions	57 (w) x 104 (d) x 28 (h) mm
Weight	110 g

Supported operating systems: Android – Linux – Windows – macOS

Plug.n.DAQ Lite Software Compatibility: ARTA – Audacity – DASYLab – imc WAVE – LabVIEW – ME’Scope – NVH-IMP – NVH-FFT – Visual Analyzer – WavePad Sound Editor – Sigview – Soundcard Oscilloscope – SO Analyzer – SpectraPLUS-RT – SpectraPLUS-SC – Multi-Instrument

PS-24-DIN

IEPE Power Supply for DIN Rail

The PS-24-DIN provides 4 mA/24V supplies for sensors with integrated amplifiers like IEPE measurement microphones , accelerometers, force and pressure transducers.
The PS-24-DIN are mountable for standard industrial
applications.

1-channel IEPE supply
24V/4mA
Supply Voltage min. 24 V DC max. 32 V DC +- 5%
Constant Current, to sensor 4.3 mA
Voltage Gain × 1
Output voltage max.: 10 Volt^RMS
Frequency response: 0.05 Hz to 350 kHz (-0.2 dB) (with external input resistance of 1 MΩ)
Operating temperature 0 °C – 70 °C
Storage temperature 0 °C – 85 °C
Dimensions L x W x H 58 x 36 x 90 mm

8201T

1 Channel IEPE Sensor Supply

8201T is a portable single channel IEPE sensor signal conditioner.

It provides a 24 V / 4 mA power supply for sensors with integrated amplifiers.

The frequency response goes from 0.3 Hz to 300 kHz, so this is perfectly adequate for most IEPE sensors.

8201T is equipped with a high-quality, sturdy aluminum housing.

The included transformer plug-in power supply with true galvanic isolation avoids common-mode problems caused by ground loops.

1-channel IEPE supply
24V/4mA
Output voltage max.: 10 Volt^RMS
Frequency response: 0.3 Hz to 300 kHz (-0.5 dB)

8201

1-channel IEPE supply
24V/4mA
0, +20 dB
Output voltage max.: 5 Volt eff
Frequency response: 0.3 Hz to 300 kHz (-0.5 dB)

Portable IEPE Sensor Amplifier

8201 is a portable single channel IEPE sensor signal conditioner.

It provides a 24 V / 4 mA power supply for sensors with integrated amplifiers.

Two selectable gains 0dB and + 20dB are available.

Signal conditioning indicators minimize the risk of operator error.

The integrated rechargeable 9 volt battery is designed for a long operating time of more than 4 hours.

Recharging can be done during operation.

The frequency response goes from 0.3 Hz to 300 kHz, so this is perfectly adequate for most IEPE sensors.

The 8201 is equipped with a high-quality, sturdy aluminum housing.

Provides power for microphones, accelerometers and other ICCP transducers

2 channel input/output with BNC connector
LED indicators show the status of each input channel
4 mA/24 V ICCP power supply
7 V~30 V wide voltage DC power supply
Frequency Response 0.4 Hz ~ 200 kHz (±3 dB)

MC102A power supply can provide power for prepolarized microphones, accelerometers and other ICCP compatible transducers. It has two channels input/output with BNC connector, and wide voltage power supply supports the use of various DC power supplies.

MC102A is compatible with microphones or transducers using any of the above proprietary names.

MC102A has an all-aluminum housing, which can effectively shield the internal signal.

The LED indicators display the power supply status and the input status of each channel (input open (sensor not connected), OK (sensor connected), and input shorted).

Each channel has a 35Vp input and output protection circuit, which can protect sensors and data acquisition equipment.

AV14S

IEPE Amplifier with Headphone Output

The 1-channel IEPE amplifier AV14S is a small accumulator-driven instrument, which has been constructed mainly to monitor acoustic or vibration signals. It has 1 measuring channel for an IEPE microphone or IEPE accelerometer. A headphone output is built in for monitoring purposes. The loudness of the headphone can be adjusted by the potentiometer on the right side of the instrument.

At the output socket you get a voltage proportional to the acceleration or sound pressure independent of the amplification of the headphone amplifier. So the instrument can be used as a front end for analyzers or similar instruments.

USES

Acoustic and Vibration Measurements
Source Location
Machine Diagnostics

FEATURES

IEPE Sensor input
Adjustable Headphones output
Preamplifier Function (additional output)

®TRADEMARK

ICP is a registered trademark of PCB Piezotronics, Inc., DeltaTron is a registered trademark of Hottinger Brüel & Kjær A/S, ISOTRON is a registered trademark of ENDEVCO.

This document only describes the technical principles involved and inevitably mentions the registered trademarks of other manufacturers, which is not intended and will not harm the interests of trademark owners. The registered trademarks mentioned above belong to their respective owners.
